Indicator Light

Indicator Light

NSN NUMBER

6210010535100

Lamp bulb size designator: t-1 3/4

Lamp type accommodated and quantity: 1 incandescent

Material: aluminum body

Furnished items and quantity: 1 hexagon nut and 1 lock washer

Spec/std controlling data:

Lens quantity: 1

Overall length: 1.250 inches maximum

Non-definitive government spec/std reference: mil-l-3661

Mounting method: panel

Lens back surface condition: frosted single light 1st position horizontal

Terminal type and quantity: 2 solder lug

Hazardous locations/environmental protection: watertight

Lens mounting method: screw in

Overall diameter: 0.640 inches nominal

Lamp base type accommodated: midget flanged

Transmitted light color: red single light 1st position horizontal full display division a

Style designator: a1 round frame, round lens type

Lens light transmission characteristic: translucent single light 1st position horizontal

Lens color: red single light 1st position horizontal

Lens type: stovepipe, short shank single light 1st position horizontal

Panel accommodation hole diameter: 0.465 inches minimum and 0.471 inches maximum

Definitive government spec/std reference: lh89/1-lc35rt2

Panel thickness for which designed: 0.188 inches maximum

Lens face surface condition: smooth single light 1st position horizontal
